V 2025 / V 2533 / U 1040 / U 1545 / U 2050
 |
|
|
|
V2025
|
V2533
|
U1040
|
U1545
|
U2050
|
|
Tracing W/L mm
|
2000/2000
|
2500/2000
|
1000/2000
|
1500/2000
|
2000/2000
|
|
Cutting W/L mm
|
2500/7500
|
3300/7500
|
4000/7300
|
4500/7300
|
5000/7300
|
|
Rail length mm
|
9600 = (2400 × 4)
|
|
Number of torches
|
12 (max.)
|
20 (max.)
|
|
Speed range mm.min
|
50 ~ 1,250
|
50 ~ 800
|
|
Optical tracer
|
Photo electric tracer TLE-72XM
|
|
Tracing silhouette
|
Line / edge
|
|
Tracing accuracy
|
± 0.3mm
|
|
Kerf compensation
|
± 5mm
|
|
Power source
|
AC 100V 50/60Hz
|
|
Machine weight
|
1,300kg
|
1,500kg
|
2,500kg
|
2,800kg
|
3,100kg
|
|
